    Efficiency 2000 CNC Gantry DRILL Machine φ70 U Drill YCLMZ-2000

    Ask Lasest Price
    Brand Name : Vicord
    Model Number : YCLMZ-2000
    Certification : CE
    Payment Terms : L/C,T/T
    Supply Ability : 500 units/year
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Efficiency 2000 CNC Gantry DRILL Machine φ70 U Drill YCLMZ-2000

    Efficiency 2000-CNC Gantry DRILL


    Characteristic


    This machine tool is arranged with a gantry moving column layout, featuring stable structure and space-saving.


    Easy to operate: This machine tool can be mastered by anyone without machining experience after just one lesson.


    Simple and fast operation, improves work efficiency, saves labor, and reduces costs.


    Specifitions


    ProjectMachine tool specificationYCLMZ-2000
    Technical
    specifications
    Table size2000 x 2000
    Maximum drilling diameterφ70 U drill
    Distance from spindle and face to workbench250/800
    X-axis stroke2100mm
    Y-axis stroke2100mm
    Z-axis stroke650mm
    T-slot spacing230mm
    Servo spindle11KW
    Principal axisBT50
    Machining precisionRepeated positioning accuracy±0.03
    Machining position accuracy±0.04
    Main transmissionTransmission fromSynchronous belt
    Spindle motor range(r/min)400-6500
    Numerical control systemKaiendi K1000MFli
    Feed formActuating motor15N.m/10N.m/7.7N.m
    Machine AppearanceOverall dimension of machine tool
    (length x width x height) (mm)
    4300 x 3500 x 2700
    Machine tool weight(ton)12.5 tons

    Process Product
