    Double Sided CNC Boring Lathe 43-87r/Min 8500KG Cnc Boring Mill For Sale

    Ask Lasest Price
    Brand Name : Vicord
    Model Number : YC II C800HT
    Certification : CE
    Payment Terms : L/C,T/T
    Supply Ability : 500 units/year
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Double Sided CNC Boring Lathe 43-87r/Min 8500KG Cnc Boring Mill For Sale

    Double-Sided CNC Boring Lathe


    The machine tool is controlled by a numerical control system, which is simple and fast to operate. Two surfaces are processed simultaneously, which is fast and improves work efficiency, saves labor, and reduces costs.


    Application


    The machine tool is suitable for various types of gearboxes and turbine boxes: it ensures the machining of two surfaces or holes that require parallelism and concentricity, with high processing efficiency, reduced manual labor, high uniformity of machining dimensions, and simple operation.


    Characteristic


    High processing efficiency: In the processing process, CNC machines use the method of working with power heads simultaneously, allowing the machining of two surfaces or holes to be completed within the same time frame.


    Reduce manual labor: one person operates two lathes.


    High uniformity in processing dimensions: This machine tool fully adopts a numerical control system, eliminating the need for repeated tool setting, thereby improving the uniformity of dimensions.


    Easy to operate: The machine tool adopts a numerical control system, and those with numerical control experience can learn it immediately.


    Details


    ProjectMachine tool specificationYC II C300HTYC II C400HTYC II C600HTYC II C800HT
    Technical
    specifications
    Maximum turning length(mm)φ460φ580φ840φ1025
    Maximum machining length(mm)60080010001100
    Minimum machining length(mm)200300300400
    X-axis travel(mm)170270450570
    Z-axis travel(mm)280395450450
    Machining precisionCoaxiality(mm)≤0.1≤0.1≤0.15≤0.2
    Parallelism(mm)≤0.1≤0.1≤0.15≤0.2
    Surface roughness6.36.36.36.3
    Spondle driveTransmission from (Gearshifting)Fourth speed changeThird speed changeSecond speed changeThird speed change
    Spindle motor range(r/min)72-25669-15732-4743-87
    Spindle motor modelYE2-132M-6-5.5KWYE2-132M-6-5.5KWYE2-160L-8-7.5KWYE2-180L-8-11KW
    Numerical control system(optional)Nanjing Huaxing--Step System Nanjing Huaxing--Servo System
    GuangZhou cnc--Stepping GuangZhou cnc--Servo System
    Feed form(optional)Stepmptor24 N.m24 N.m35 N.m50 N.m
    Actuating motor7.7 N.m7.7 N.m10 N.m15 N.m
    Machine AppearanceFull protectionOverall dimension of machine tool
    (length x width x height) (mm)
    3800 x 1500 x 17004500 x 1800 x 22005000 x 1800 x 22005400 x 2300 x 2500
    Simple protectionOverall dimension of machine tool
    (length x width x height) (mm)
    3600 x 1500 x 17004350 x 1800 x 22004800 x 1800 x 22005200 x 2300 x 2500
    Machine tool weight(kg)2800400057008500

    Process Product
